Маршрутизатор Huawei 02354250 [AR2204]

System parameters

Processor

Dual-core, 800 MHz

Memory

1 GB

Flash

512 MB

Micro SD card (default: sd1)

None

Hard disk

Not supported

Dimensions and weight

Dimensions (H x W x D)

• With no mounting bracket installed: 44.4 mm x 442.0 mm x 420.0 mm (1.75 in. x 17.40 in. x 16.54 in.), 1 U height
• With mounting brackets installed: 44.4 mm x 482.6 mm x 420.0 mm (1.75 in. x 19.00 in. x 16.54 in.), 1 U height

Weight

6 kg (13.23 lb)

Power specifications

Rated AC input voltage

100 V/240 V, 50 Hz or 60 Hz

Maximum input voltage range (AC)

90 V AC to 264 V AC, 47 Hz to 63 Hz

Maximum input current

3 A

Maximum output power

150 W

RPS power supply

Supported

PoE power supply

Not supported

Power consumption (empty chassis)

Typical power consumption

35 W

Maximum power consumption

55 W

Heat dissipation

Fan module

Built-in fan module, not swappable

Airflow (facing the front panel)

Left-to-right

Interface density

Management interfaces

1 (RJ45)

CON/AUX interface

1 (RJ45)

USB 2.0 interfaces

2

Service interfaces (standard configuration)

WAN interfaces: one GE combo interface and two GE electrical interfaces

Extended slots

4xSIC

Environment parameters

Storage temperature

-40°C to +70°C (-40°F to +158°F)

Operating relative humidity

5% to 95%, noncondensing

Operating altitude

< 5000 m (16404.2 ft.)

Part number

02354250
